Equipment

Optical 3D profilometer Rtec UP-2000

The device is essential for visualization and height measurement of structures produced during lithography, enabling the selection of appropriate microfabrication protocols for molds/stamps and prototype microfluidic devices.



Maskless lithography system KLOE Dilase 650

The installation scheduled for the end of February 2026.
The device enables efficient microfabrication prototyping, in particular the fabrication of molds/stamps and prototype microfluidic devices using photolithography.



Inverted microscope Nikon Eclipse Ti2-U equipped with a laser set, data acquisition card, and optical table

The installation scheduled for March 2026.
The system includes an inverted microscope featuring a detector connection port, objectives with magnifications of 4×, 10×, 20×, 40×, and 60×, a high-speed camera, and a fluorescence detection module. The laser set generates a coherent, multi-color light beam with stable power, used for multiplex fluorescence measurements and light-scattering detection in droplets The data acquisition card is essential for high-throughput analysis and processing of optical signals recorded by the detectors. The optical table provides vibration isolation and forms part of a dedicated setup for conducting microfluidic experiments within the project.
